Cast steel globe valve

Globe and stop check valves require higher closing torques than gate valves with the same seat diameter and pressure class. The most economical mechanism for tight shutoff is the impactor handwheel. Two lugs cast under the wheel strike simultaneous blows and give 3–10 times the closing force of standard handwheels. Impactor handwheels are supplied at manufacturer’s option unless specified by customer.

Applicable Standard

Design Standard

BS 1873, ASME B16.34, DIN3356
End flange

ASME B16.5, DIN 2501
Face to Face

ASME B16.10, EN 558, DIN 3202
Structure

Bolted bonnet ,threaded back sea, rising stem and handwheel, rotary disc
BW Ends

ASME B16.25, DIN3239

Tech Specs

Size Range

2"-24" (DN50~DN600)
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel, etc.
Stem Materials

410SS, 304SS&17-4PH, ect.
End Connection

RF, BW, RTJ
Pressure Rating

ASME CLASS 150-1500（PN16-PN250)
Ball Material

A105, 304SS, 316SS, etc.
Seat Materials

Overlay 13Cr, Stellite 6. etc.
Operation

Hand wheel, Gear, Motor, Pneumatic, Hydraulic
