Cast Steel Lift Check Valves
  • The seat design of a lift-Check valve is similar to a Globe valve. The disc is usually in the form of a piston or a ball.

  • Lift Check valves are particularly suitable for high-pressure service where velocity of flow is high. the disc is precisely guided and fits perfectly into the dashpot. Lift Check valves are suitable for installation in horizontal or vertical pipe-lines with upward flow.

Applicable Standard

  • Design Standard
    BS 1868, API 6D
  • Face to Face
    ASME B16.10
  • End Flange
    ASME B16.5, ASME B16.47
  • BW Ends
    ASME B16.25
  • Inspection and Test
    API 598

Tech Specs

  • Size Range
    2"-12"(DN50-DN300）
  • Body Materials
    Carbon Steel, Stainless Steel, Alloy Steel, etc.
  • Seat Materials
    Overlay 13Cr, Stellite 6, etc.
  • End Connection
    RF, BW, RTJ
  • Pressure Rating
    ASME CLASS 150-900 (PN16-PN150）
  • Ball Materials
    Carbon Steel, Stainless Steel, Alloy Steel, etc.
