Floating Ball Valve

Full port or reduced port
Floating ball design
Blowout-proof stem
Casting or forging body
Fire safe design to API 607/ API 6FA
Anti-static to BS 5351
Cavity pressure self relief
Optional locking device

Applicable Standard

Design Standard

API 6D, ASME B16.34, API 608, BS 5351, MSS SP-72
Face to Face

API 6D, ASME B16.10, EN 558
Applied temperature range

soft seated :-46℃~200℃,
metal seated: up to 425℃.
End Connection

ASME B16.5, ASME B16.25
Inspection and Test

API 6D, API 598

Tech Specs

Size Range

1/2"-8"(DN15-DN200）
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel etc.
Stem Materials

A105+ENP, 304SS, 316SS etc.
End Connection

RF，RTJ，NPT，BW，SW
Pressure Rating

ASME CLASS 150-600 (PN16-PN100）
Ball Materials

A105+ENP, 304SS, 316SS etc.
Seat Materials

Metal seat or soft seat RPTFE, NYLON,PEEK
Operation

Hand Lever, Gear, Motor, Pneumatic, Hydraulic
