Forged Steel Gate Valve

Solid or wedge gate
Full port or reduced port design
Bolted bonnet, welded bonnet, or pressure sealed bonnet

Applicable Standard

Design Standard

API 602, ASME B16.34, BS 5352, DIN3352
Face to Face

ASME B16.10, EN 558, DIN3202
End Flange

ASME B16.5, DIN2533
Buttwelding Ends

ASME B16.25, DIN3239
Socket Welded Ends

ASME B16.11
Threaded Ends

ASME B1.20.1
Inspection and Test

API 598, DIN3230
End connection

RF, BW, RTJ,SW ,NPT

Tech Specs

Size Range

1/2"-2" (DN15-DN50）
Body Materials

A105, 304SS, 316SS, etc.
Stem Materials

410SS, 304SS&316SS, etc.
End Connection

SW, RF, RTJ, BW, NPT
Pressure Rating

ASME CLASS 800, 150-2500 (PN16-PN420）
Ball Materials

A105, 304SS, 316SS, etc.
Seat Materials

Overlay 13Cr, Stellite 6, etc.
Operation

Hand wheel, Motor
