Metal Seated Ball Valve

Full port or reduced port
Floating ball or trunnion ball
Metal to metal seated
Blowout-proof stem
Fire safe design to API 607 / API 6FA
Anti-static to BS 5351
Cavity pressure self relief
Double seats with spring loading

Applicable Standard

Design Standard

API 6D, ASME B16.34, API 608, MSS SP-72, BS 5351
Face to Face

ASME B16.10, API 6D, EN 558
End Flange

ASME B16.5, DIN 2501
BW Ends

ASME B16.25
Inspection and Test

API 598, API 6D

Tech Specs

Size Range

1"-24"(DN25-DN600)
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel etc.
Stem Materials

XM-19, 17-4PH, F51, etc.
End Connection

RF, RTJ, BW
Pressure Rating

ASME CLASS 150-1500 (PN16-PN250)
Ball Materials

A105+ENP, F304, F316 etc.
Seat Materials

The sealing surface spray welded with nice; base alloy
Operation

Handlever, Gearbox, Motor, Pneumatic, Hydraulic
