"Orbit" Ball Valve

Integral type: firmer and safer, easier to repair
Anti-explosive: used under the working condition of flammable.
Fireproof design :insure sealing in when flaming.
High-pressure resistance: easy operation on high working pressure working condition.
Sealing capacity: reliable sealing performance

Applicable Standard

Design Standard

API 6D, ASME B16.34
Face to Face

API 6D, ASME B16.10
End Flange

ASME B16.5,
BW Ends

ASME B16.25
Inspection and Test

API 6D, API 598

Tech Specs

Size Range

3/4"-24"(DN20-DN600）
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel etc.
Stem Materials

XM-19, 17-4PH, etc.
End Connection

RF，RTJ，BW
Pressure Rating

ASME CLASS 150-2500（PN16-PN420）
Ball Materials

A105+ENP, F304, F316, etc.
Seat Materials

The sealing surface spray welded with nickel base alloy
Operation

HandLever, Gear, Motor, Pneumatic, Hydraulic
