Single Weld Joint Ball Valve
  • Fully-welded ball valve is widely used in oil and natural gas gathering and pipeline transportation, Our single weld joint ball valve are developed by our technician, artistically designed and more practical. Our ball valve is in accordance with two-way sealing valve seat, automatic discharge pressure at the same time, fire prevention, anti-static function.
  • Small volume, Light weight, Split & Fixed type metal or soft sealing, Double seat, Double block and bleed, Single weld structure, Advanced manufacuture technology, Reasonable sealing, Stable performance, Long life.

Applicable Standard

  • Butt Welding Size
    ASME B16.25
  • Pressure-Reference Temperature
    ASME B16.34
  • Prevent Electrostatic Design
    Fireproofing Design API 607/6FA
  • Pressure Rating
    Class 150 LB - Class 600 LB
  • Connection
    Buttweld
  • Material
    A105, LF2, F304, F316, F304L, F316L, F321, F51, F53
  • Drive Method
    Manual, Gear Box, Electro-motion, Pneumatic, Linkage

Design Features

  • Design & Manufacturing Standard
    API 6D, ASME B16.34, API 608, MSS SP-72, BS 5351
  • Structure Length Size
    ASME B16.10 ，API 6D，EN 558
  • End Connection Size
    ASME B16.5，ASME B16.47 (DIN 2501)
  • Butt Welding Size
    ASME B16.25
  • Pressure-Reference Temperature
    ASME B16.34
  • Test and inspection
    API 598，API 6D
  • Prevent Electrostatic Design
    Fireproofing Design API 607/6FA

Tech Specs

  • Size Range
    2"-56" (DN25-DN1400）
  • Body Materials
    A105, F304, F316, etc.
  • Stem Materials
    410SS, 17-4PH, F51, etc.
  • End Connection
    RF，RTJ，BW
  • Pressure Rating
    ASME CLASS 150-500 (PN16-PN420）
  • Ball Materials
    A105+ENP, F304, F316, etc.
  • Seat Materials
    PTFE，PEEK，NYLON
  • Operation
    Hand lever, Gear, Motor, Pneumatic, Hydraulic
