Lock Slag Ball Valve
  • Split-type body and trunnion ball design, to avoid excessive pressure on the valve seat and damaged seat.
  • The ball and the valve stem are designed and processed in an integrated manner to ensure the ball and stem in the centre line of valve, and avoid the valve stem disengagement by the frequent opening.
  • Used Inconel X-750 spring or high temperature resistant Viton
  • The valve seat has the self-scraping function then realize the self-cleaning of the spherical surface

Applicable Standard

Design Standard
API 6D, ASME B16.34
Face to Face
ASME B16.10
End Flange
ASME B16.5
BW Ends
ASME B16.25
Inspection and Test
API 598 /ASME B16.104

Applicable Standard

  • Design Standard
    API 6D, ASME B16.34
  • Face to Face
    ASME B16.10
  • End Flange
    ASME B16.5
  • BW Ends
    ASME B16.25
  • Inspection and Test
    API 598 /ASME B16.104

Tech Specs

  • Size Range

    1"-24" (DN25-DN600）
  • Body Materials

    Carbon Steel, Stainless Steel, Alloy Steel, etc.
  • Stem Materials

    XM-19,17-4PH,F51, etc.
  • End Connection

    RF，RTJ，BW
  • Pressure Rating

    ASME CLASS 150-2500 (PN16-PN420）
  • Ball Materials

    The sealing surface be spray welded nickel base alloy
  • Seat Materials

    The sealing surface be spray welded nickel base alloy
  • Operation

    HandLever, Gear, Motor, Pneumatic, Hydraulic
