Triple Eccentric Butterfly Valve
  • The yoke is designed according to ISO5211, which is convenient for installing gearbox, pneumatic or electric actuator.
  • Anti-valve stem blowout design
  • low leakage packing (optional), advanced metal-bonded graphite packing (for the bottom and top ) and low leakage packing (for the middle) to ensure a maximum leakage no less than 20ppm
  • Extend the bearing design, the use of long precision bearings, reduce valve stem friction, to ensure low operating torque, graphite ring is used to prevent pollutants from entering the bearing
  • Multi-layer seal design, elastic deformation of the seal ring can guarantee zero leakage, the seal ring is truly interchangeable, convenient maintenance
  • The valve seat surfacing hard alloy, the overall hardened valve seat, extending the life of the valve, reducing the number of maintenance.

Applicable Standard

  • Design Standard
    API 609, MSS SP-67, MSS SP-68, BS 5155
  • Structure
    lug type, wafer type, double flange type, butt welding type
  • Face to Face
    API 609, ASME B16.10, BS 5155, EN1092
  • End Flange
    ASME B16.5, ASME B16.47
  • BW Ends
    ASME B16.25

Tech Specs

  • Size Range

    2"-128"(DN50-DN3200）
  • Body Materials

    Carbon Steel, Stainless Steel, Alloy Steel, Nickel Aluminum Bronze, etc.
  • Stem Materials

    410SS, 304SS&17-4PH, etc.
  • Body Style

    Wafer, Lug and Double Flanged
  • Pressure Rating

    ASME CLASS 150-600 (PN16-PN100）
  • Ball Materials

    Carbon Steel, Stainless Steel, Alloy Steel, Nickel Aluminum Bronze, etc.
  • Seat Materials

    316 SS Hardened PTFE, Graphite Laminated
  • Operation

    Hand lever, Gear, Motor, Pneumatic, Hydraulic
