Trunnion ball valve

O-rings and gaskets to prevent leakage between the body and bonnet
Floating seat with pre-tensioned spring ensures sealing even at low pressure
Injection sealant (grease) device, in case of emergency
screw plug, discharge dirt inside the valve cavity

Applicable Standard

Design Standard

API 6D, ASME B16.34, BS 5351, API 608, MSS SP-72
Face to Face

ASME B16.10, API 6D, EN 558
End Flange

ASME B16.5,ASME B16.47, DIN 2501
BW Ends

ASME B16.25
Inspection and Test

API 598, API 6D

Tech Specs

Size Range

2"-56"(DN25-DN1400）
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel etc.
Stem Materials

A105+ENP, F304, F316 etc.
End Connection

RF，RTJ，BW
Pressure Rating

ASME CLASS 150-1500（PN16-PN250）
Ball Materials

A105+ENP, F304, F316 etc.
Seat Materials

Metal seat or Soft seat PTFE，PEEK，NYLON
Operation

Hand lever, Gear, Motor, Pneumatic, Hydraulic
