Wedge Gate valve

Metal-wrapped flexible graphite gasket for 150LB, metal-wound gasket for 300LB and 600LB, metal gasket for 900LB and above, or 600LB according to customer’s requirement.
CoCr alloy hard faced, ground and lapped to a mirror finish.
Bolted bonnet, outside screwed stem and yoke, threaded back seat. rising stem, flexible wedge gate.

Applicable Standard

Design Standard

API 600, BS1414, DIN3352
Structure

Bolted bonnet, outside screwed stem and yoke, threaded back seat. rising stem, flexible wedge gate.
Face to Face

ASME B16.10, EN 558, DIN3202
End Flange

ASME B16.5, ASME B16.47, DIN2533
BW Ends

ASME B16.25, DIN3239
Inspection and Test

API 598, DIN3230

Tech Specs

Size Range

2"-60" (DN50-DN1200）
Body Materials

Carbon Steel, Stainless Steel, Alloy Steel, etc.
Stem Materials

410SS, 304SS&17-4PH, etс.
End Connection

RF, BW, RTJ
Pressure Rating

ASME CLASS 150-2500 (PN16-PN420）
Wedge Materials

Carbon Steel, Stainless Steel, Alloy Steel, etc.
Seat Materials

Overlay 13Cr,Stellite 6, etc.
Operation

Hand wheel, Gear, Motor, Pneumatic, Hydraulic
